How Many Downpipes Per Square Metre Of Roof

This is because larger roofs require bigger volumes of water to be diverted away from them during periods of rainfall.

How many downpipes per square metre of roof.

The example s roof plan area is 185 sq m and the factored x 1 21 roof catchment area is 223 8 sq m. Using clause e1 table 5 see figure 2 at a roof pitch of 45 for this example. In general gutters are available in different forms and numerous applications such as suspended gutters box gutters valley gutters etc. This free roofing calculator estimates the area of a roof and the amount of materials required to replace or build said roof.

The rainwater is guided through downpipes into a sewer other disposal point or collector. Therefore 74 mm downpipes are. How many downpipes and what size. To calculate the minimum number of downpipes divide the roof catchment area by the allowable maximum catchment per downpipe.

From figure 3 5 a in as nzs 3500 3 the maximum catchment per downpipe is 47m 2. Requires flow to be calculated in one of the other calculators. How many downpipes do you need. If a square outlet is against a wall only 3 sides will accept the flow under weir flow conditions.

Rectangular or circular downpipes. The number of downpipes you need will depend on the size of your roof and your chosen style of guttering. The example s gutter and downpipes have been calculated as compliant to harvest a maximum factored roof area of 47 square metres. Down pipe size not listed a few of the uncommon pipe sizes are not listed eg sizes smaller than 90mm 125mm dia etc.

The roof slope as per the code should be 12 5 deg. Allows for any shape of rwh. Roof area the locale s rainfall intensity and gutter capacity determine how many square inches of downspout are needed. 63 mm diameter downpipes serve roof plans up to 35 m 74 mm diameter downpipes serve roof plans up to 50 m.

The downpipes are sized to suit the roof area as well as the roof pitch so. Explore a number of housing related calculators as well as hundreds of other calculators covering topics such as finance math health fitness and more. Rectangular or circular spitters any number of circular spitters and reduction in down pipe size by using a funnel section. Select 100 x 50 rectangular downpipe.

A square inch of downspout can drain 1 200 square feet of roof during a rain with an intensity of one inch per hour. Doubling the number of downspouts halves the required capacity for each. Determine minimum number of downpipes. Total roof area 50m2 serviced roof area 25m2 flow capacity 25 x 1 67 41 75l min min gutter area 41 75 0 0016 0 8 3413 73mm2 with a centrally located outlet all marley spouting profiles could be used.

Gutters are produced in many variations and their use is various.
